AC/DC Voltage Measurement Accuracy Range 600.0 V Resolution 0.1 V 50 Hz to 400 Hz ± (% of Rdg + Digits) ±(2% + 3) Input impedance 3 MΩ (nominal), < 100 pF Common mode rejection ratio (1 kΩ unbalanced): > 60 dB at DC, 50 or 60 Hz Overload protection 600 V rms or DC Earth Bond Resistance Measurement Range/Resolution 20.00 Ω 0.01 Ω 200.0 Ω 0.1 Ω 2000 Ω 1.0 Ω 20.00 kΩ 0.01 kΩ Accuracy ±(1.5% + 3) Overload protection 2 V rms or DC Open circuit test voltage > 4.0 V, < 8 V Short circuit current…
Rugged, compact advanced insulation resistance tester for electrical contractors and industrial and commercial electricians
Automatically calculates Polarization Index and Dielectric Absorption Ratio
Makes repetitive tests simple and easy with a Compare (Pass/Fail) function
Offers multiple insulation test voltages: 50 V, 100 V, 250 V, 500 V, and 1000 V
