MS-POE – MICROSCANNER POE CABLE VERIFIER

Description

Product Overview

The MS‑POE MicroScanner PoE Cable Verifier is a rugged handheld tool designed for troubleshooting and verifying Ethernet cabling systems. It combines cable diagnostics, PoE (Power over Ethernet) analysis, wire mapping, and tone generation into one device—greatly reducing test time and minimizing errors Fluke+12Fluke Networks+12specialized.net+12.

⚙️ Key Features

• PoE Detection & Analysis

  • Detects PoE class (0–8) for standards 802.3af, 802.3at, 802.3bt, and Cisco UPOE

  • Displays available voltage even from passive power sources specialized.net+1Fluke Networks+1ADI Global Distribution+4Fluke+4Fluke Networks+4specialized.net+2ADI Global Distribution+2Fluke Networks+2

  • Graphical display of which pairs are powered (2‑ or 4‑pair detection) Fluke Networks

• Network Speed Identification

  • Detects link speed up to 10 Gbps—supports 10/100/1G/2.5G/5G/10G Ethernet ADI Global Distribution+1Amazon+1specialized.net+5Fluke Networks+5ADI Global Distribution+5

• Cable Testing & Diagnostics

  • Graphical wire map: pin mapping, opens, shorts, crosses

  • Measures cable length and distance-to-fault (up to ~460 m, 0.3 m resolution) Fluke+11RS Components+11Fluke Networks+11

• IntelliTone™ Tone Generator

  • Supports both digital and analog toning for easy cable tracing in complex environments Connection+5Fluke Networks+5RS Components+5

📦 Kit Contents

• MicroScanner PoE unit with wiremap adapter

• 2 × AA batteries (≈20 h runtime)

• Soft carry pouch (some kits include IntelliTone Pro 200 probe & remote IDs) Fluke+12RS Components+12specialized.net+12

Optional kits (MS‑POE‑KIT / industrial versions) may include multi‑connector cables for M12/M8 cables, IntelliTone Pro 200 probe, and remote identifier modules Fluke Networks+3RS Components+3Fluke+3.

📐 Technical Specs

• Display: Backlit monochrome LCD

• Power: 2 × AA batteries (~20 h typical runtime) RS Components+1Fluke Networks+1

• Size & Weight: ≈ 16.3 × 7.6 × 3.6 cm; ~300 g RS Components+1Fluke Networks+1

• Operating Range: 0 °C to 45 °C; drop‑tested to 1 m; humidity tolerance up to 90% RS ComponentsADI Global Distribution

• Standards Compliance: IEEE‑802.3af/at/bt; IEC 61010‑1; EMC: IEC 61326‑1 RS Components+1Fluke Networks+1

🚦 Why Choose MicroScanner PoE

• All-in-One Testing: Wiremap, length, speed, fault localization, PoE—displayed together in a single screen

• Rapid Diagnostics: Quickly identify if an issue is cabling, insufficient power, or a switch configuration problem YouTube+13Fluke+13Fluke+13Fluke Networks

• Robust Design: Rugged, rubber-overmold exterior; ideal for field and industrial environments ADI Global Distribution+1specialized.net+1

📋 Summary

The MS‑POE MicroScanner PoE offers a comprehensive solution for cable installers and network technicians, combining Ethernet diagnostics with precise PoE analysis—making it an essential tool for field verification and troubleshooting.
